Jetmaster Pro Universal 700 S with Basket Grate and Pan

A built-in open fire that keeps things simple, with its grate and pan included.

From: Original price was: R13,088.00.Current price is: R12,399.00.

Save R689
Rated 4.7 out of 5Google rating ·54 reviews

Pay in interest-free instalments with Float

SKU 40211429

In stock Delivery ETA: 5–15 working days

Complete your setup

See it in your space. Send a photo and measurements for a quote and a visual preview.

WhatsApp Us

A CLEAN, SIMPLE SETUP

Jetmaster Pro Universal 700 S.
An open fire, grate included.

Meet the Jetmaster Pro Universal 700 S: a built-in open fireplace in mild steel, with its basket grate and pan included. Light wood or charcoal in the grate, set the damper control to suit the evening and enjoy convection and radiated heat. The body is 353 mm deep, so measure your wall early and the rest falls into place.

  1. Basket grate and panWood grate 670 × 280 mm
  2. Damper controlSet the fire to suit the evening
  3. Convection and radiated heatMild-steel body
  4. Wood or charcoalGas is a separate version
  5. Installation manualUnder Plan your setup
Jetmaster Pro Universal 700 S with logs burning in the basket grate, set in a pale brick chimney breast above a low hearth, in a family room in the evening

THE QUIET HOUR

Some evenings are just for you and the flames.

The house has gone quiet, the lights are low and the logs are catching in the basket grate. Pour something warm, pull up a chair and let the fire do the talking. Save the big braai for the weekend. Tonight is about a warm room, a good seat and nowhere else to be.

The logs, brick chimney breast, hearth, furniture, flowers and décor are not included. Plan the flue, support and clearances with an independent installer.

BEFORE THE BUILDER ARRIVES

Plan early.
Enjoy the fire.

THE GRATE

Ready for logs.

There is no grate to choose: the basket grate and pan come with this fireplace, and the wood grate is 670 mm wide and 280 mm deep. Burn wood or charcoal, and use the damper control to manage the fire.

THE WARMTH

Heat you can feel from the couch.

Universal fireplaces give convection and radiated heat. The listed wood heating capacity is 68 m². We do not have a Jetmaster kW figure for this model, so use the area as a guide and ask us about your room.

THE FLUE

Your flue, your route.

The fireplace takes a 200 × 200 mm rectangular flue section. A flue adapter to a 225 mm round flue, flue pipe in 1,200 mm lengths and a rotating cowl are options here. Send a photo and measurements for a quote.

MEASURE THE WHOLE SETUP

Will it fit your space?

Open the full drawing
Jetmaster Pro Universal 700 S dimension drawing, page 1 of 2: front, side and top views and flue, in millimetres.
Page 1 of 2
Body width × depth
749 × 353 mm
Body height, without the gather
630 mm
Gather above the body
252 mm
Add to the width for the frame
100 mm
Wood grate width × depth
670 × 280 mm
Rectangular flue width × depth
200 × 200 mm
Round flue diameter (option)
225 mm
Insulation, existing masonry recess
25 mm
Fuel
Wood or charcoal
Material
Mild steel

Check the depth, then plan the gather and flue.

The 630 mm body height does not include the 252 mm gather or the flue, and you add 100 mm to the width for the frame. These are product sizes, not a building opening, so ask us for the opening size and have your installer check the actual unit and safe clearances.

Planning notes

  • Comes with a basket grate and pan.
  • For the width including the frame, add 100 mm.
  • These are product sizes, not a building-opening size. Ask us for the opening size before you build.
  • Ask us for the frame height and projection and the flue position: we confirm them with Jetmaster.
  • In an existing masonry recess, allow 25 mm all round for insulation.
  • The adaptor, flue, cowls, screens and ceramic blanket are listed as separate accessories.
  • The gas grate belongs to the gas version. It is not part of this wood fireplace.

Download printable drawing (A4 PDF)

The drawing as text
  • ALL SIZES IN MILLIMETRES
  • Jetmaster Pro Universal 700 S with Basket Grate and Pan
  • Built-in open fireplace for wood or charcoal
  • 01 FRONT VIEW
  • Damper
  • Basket grate and pan
  • 200 rectangular flue
  • 252 gather
  • 630 body height
  • 670 wood grate
  • 749 body width
  • 02 SIDE VIEW
  • 200 rectangular flue
  • 353 body depth
  • Front at the right.
  • 03 TOP VIEW
  • 749 body width
  • 353 body depth
  • Front at the bottom. White: the flue outlet.
  • 04 FLUE ACCESSORIES
  • 200 width
  • 200 depth
  • 225 diameter
  • Rectangular flue
  • Round flue
  • 1,200 length
  • One length of round flue
  • 05 WOOD GRATE (INCLUDED)
  • 670 width
  • 280 depth
  • 06 GAS GRATE (OPTION)
  • 650 width
  • 270 depth
  • PLANNING NOTES
  • Comes with a basket grate and pan.
  • For the width including the frame, add 100 mm.
  • These are product sizes, not a building-opening size. Ask us for the opening size before you build.
  • Ask us for the frame height and projection and the flue position: we confirm them with Jetmaster.
  • In an existing masonry recess, allow 25 mm all round for insulation.
  • The adaptor, flue, cowls, screens and ceramic blanket are listed as separate accessories.
  • The gas grate belongs to the gas version. It is not part of this wood fireplace.

GOOD TO KNOW

Plan your setup.

Start with your installation manual, then plan the wall and the flue.

Read the instruction manual

What is included?

The main unit: a built-in open fireplace in mild steel with damper control, including the basket grate and pan. The flue adapter, round flue pipe, rotating cowl and insulation blanket are options on this page, sold separately. Ask us to confirm the full parts list for your order.

Which fuel can I use?

Wood or charcoal. Gas options are separate versions, so the gas grate on our drawing is not part of this fireplace. Ask us if you would rather burn gas.

How big is the basket grate?

The wood grate is 670 mm wide and 280 mm deep. That is the size of the grate, not of the firebox opening.

Does it come with a log pan as well?

No. This version comes with the basket grate and pan. A log pan belongs to another version of the fireplace, so ask us if you would prefer one.

How much heat does it give?

Universal fireplaces give convection and radiated heat. The listed wood heating capacity is 68 m², which is a guide to room area and not a heat output. We do not have a Jetmaster kW figure for this model, so send us your room size and we will help you compare.

Is the flue included?

No. The adaptor, flue, cowls, screens and ceramic blanket are listed as separate accessories. A flue adapter, round flue pipe, rotating cowl and insulation blanket are options on this page. Send a photo and measurements for a flue and configuration quote, and we will confirm the parts for your setup.

What size is the flue?

The rectangular flue section is 200 × 200 mm and the round flue diameter is 225 mm. One length of round flue is 1,200 mm. These sizes describe the flue parts. They are not a cut-out in your building. Ask us for the flue position before you build.

How much space do I need?

The body is 749 mm wide, 353 mm deep and 630 mm high. The gather is a further 252 mm, before the flue, and you add 100 mm to the width for the frame. These are product sizes, not a building opening. Ask us for the opening size and for the frame height and projection before you build: we confirm them with Jetmaster.

Can it go into an existing masonry recess?

In an existing masonry recess, allow 25 mm all round for insulation. That allowance is for this kind of recess only. It is not a finished opening size or a clearance from combustible materials. The insulation blanket is an option on this page. Have your installer check the rest.

Which parts of the installation manual apply?

The South African Jetmaster installation booklet applies to this Universal model. It also covers other models and has gas chapters, so follow the sections for this fireplace. Where a size in the booklet differs from this page, ask us first.

What does the guarantee cover?

Universal fireplace boxes are listed with a five-year Jetmaster guarantee against faults in materials and workmanship. It applies to normal domestic use, with proof of purchase, correct installation and maintenance, and its exclusions apply. Accessories have separate cover. Ask us for the full terms.

Can you help with my setup?

Yes. Send a photo and measurements for a product and flue configuration quote. We do not install, so arrange installation with an independent installer.
