THE HEAT
Fans that move the warmth.
Two built-in fans give 180 m³/h of warm convection air. A thermo switch controls them, and a separate controller lets you choose the speed, from a gentle flow to a faster push.
Sale!
About your fireplace
- Heat
- 10 kW nominal, 12 kW maximum on wood
- Included
- The 2520S insert in black, with an ash tray, two built-in fans and a fan speed controller
- Not included
- Three-sided and bottom trim (optional), flue pipes, convection ducting, installation
- Guarantee
- 5 years on the stove body; 1 year on electrics
Dovre 2520S Closed Combustion Built-in Fireplace
A closed-combustion insert for your wall, with two fans to spread the warmth.
Original price was: R56,250.00.R52,899.00Current price is: R52,899.00.
Save R3,351In stock Delivery ETA: 5–7 working days
See it in your space. Send a photo and measurements for a quote and a visual preview.
WhatsApp UsFANS, FIRE AND FUEL
Built into your wall.
Fans to share the heat.
Light the fire, close the door and let two built-in fans move warm air into the room. A thermo switch looks after the fans, and a separate controller sets their speed. The firebox takes logs up to 50 cm long and burns wood, coal or lignite briquettes, so you can use what you have. The ash tray keeps the clean-up simple.
The fans need a 230 V electrical connection near the fireplace.
- Two built-in fans with speed control180 m³/h fan output
- Fan thermo switch and separate speed controller
- Two convection-air connections on topØ 125 mm each
- Logs up to 50 cm longWood, coal or lignite briquettes
- Ash trayIncluded
- Installation manualUnder Plan your setup
WHEN THE NIGHT TURNS COLD
A warm room to come home to.
Winter evenings call for a proper fire. Load a few logs, close the door and let the fans carry the warmth across the room. The dog claims the rug, someone finds a blanket, and nobody is in a hurry to go anywhere.
The stone chimney breast, hearth, log bucket, rug and furniture are not included, and the three-sided and bottom trim is an optional extra. Plan the flue, hearth and clearances with an independent installer.
BUILT FOR COLD NIGHTS
How it heats, burns and connects.
THE FIRE
Room for 50 cm logs.
Dovre rates the 2520S for wood, coal and lignite briquettes. The firebox takes logs up to 50 cm long, and the ash tray collects the ash. Follow the manual for each fuel.
THE CONNECTIONS
Flue and air ducts on top.
The 150 mm flue connects at the top, and two 125 mm convection-air connections sit beside it. Plan the flue route and any ducting with an independent installer before the wall goes up.
MEASURE THE WHOLE SETUP
Will it fit your space?
- Insert width × height
- 690 × 600 mm
- Insert depth
- 430 mm
- Flue connection diameter
- 150 mm
- Flue centre from the rear
- 120 mm
- Convection-air connection diameter
- 125 mm
- Convection-air centres, left to right
- 540 mm
- Convection-air centres from the rear
- 75 mm
- Weight
- 160 kg
- Fuel
- Wood, coal or lignite briquettes
- Finish
- Black
Plan the opening, flue and ducts together.
These are the insert's own sizes, not a building opening. No standard cut-out size is given, so have an independent installer set the opening, flue, ducts and clearances from the manual.
The drawing as text
- Dovre 2520S. Closed appliance, all dimensions in mm.
- Front: width 690 mm
- Front: height 600 mm
- Top: depth 430 mm
- Top: convection-air connections Ø 125 mm, centres 540 mm apart
- Top: convection-air connection centres 75 mm from the rear
- Top: flue connection Ø 150 mm, centre 120 mm from the rear
- Front and top at the same scale.
GOOD TO KNOW
Plan your setup.
Read your instruction manual before you plan the installation.
What is included?
The Dovre 2520S insert in black, with an ash tray, two built-in fans, a fan thermo switch and a separate speed controller. The three-sided and bottom trim is an optional extra that you can choose on this page. Flue pipes, convection ducting, the electrical connection and installation are not included.
Which fuel can I burn?
Dovre rates the 2520S for wood, coal and lignite briquettes. The firebox takes logs up to 50 cm long. Follow the instruction manual for each fuel.
How much heat does it give?
On wood, Dovre rates the 2520S at 10 kW nominal output and 12 kW maximum, with 80% efficiency. At its lowest, it gives 3.3 kW. The Output Calculator uses 11 kW, the middle of the nominal and maximum output. Insulation, ceiling height and climate change how warm a room feels.
How do the fans work?
Two built-in fans give 180 m³/h of warm convection air. A thermo switch controls them, and a separate controller sets the speed. They need a 230 V, 50 Hz electrical connection (0.5 A), so plan a power supply near the fireplace with a qualified electrician.
What are the convection-air connections?
The 2520S has two 125 mm convection-air connections on top, 540 mm apart between centres, with their centres 75 mm from the rear. Ask your installer how to connect them for your room.
Where does the flue connect?
At the top. The flue connection is 150 mm in diameter, and its centre is 120 mm from the rear of the insert. Have an independent installer plan the flue route, height and support for your building.
Is the flue included?
No. The flue pipes and cowl depend on your room and roof. Send a photo, your room measurements and roof details for a product and flue configuration quote.
How much space do I need?
The insert is 690 mm wide, 600 mm high and 430 mm deep, and it weighs 160 kg. These are the insert's own sizes, not a building opening, and no standard cut-out size is given. Your installer sets the opening and the clearances from the manual, and checks that the floor or plinth can carry the weight.
Does it need outside air?
Dovre's specification lists no outside-air connection for the 2520S. Ask your installer whether your room needs extra ventilation for a closed-combustion fireplace.
Can the door open the other way?
Yes. The door opening direction can be changed. Tell us which way you want it to open when you order, and we will confirm it with you.
What does the guarantee cover?
Dovre gives a 5-year limited warranty on the main stove body and 1 year on the electrical components. Ask us for the full terms.
Can you help with my setup?
Yes. Send a photo and measurements for a product and flue configuration quote. We do not install, so arrange installation with an independent installer.
