Homefires 5 Burner Flat Top Gas Griller

Five burners, three round-bar grids and room for the whole round.

Original price was: R19,540.00.Current price is: R18,399.00.

Save R1,141
Rated 4.7 out of 5Google rating ·54 reviews

Pay in interest-free instalments with Float

SKU GASBRSH9905FLAT

In stock Delivery ETA: 5–7 working days

About your braai

Gas
LPG · 17.5 kW heat output
Included
Two large and one small round-bar grid, vaporiser plates, drip tray, dust cover
Not included
Regulator with hose, gas pipes and fittings, roasting dome, rotisserie kit, installation
Guarantee
12 months from purchase, on Home Fires warranty terms

Free delivery in Central Gauteng on orders from R5,500. Other areas: delivery cost on request.

How delivery works

DeliveryHow it works

Because most of our products are huge, it’s difficult for us to keep stock of all of them. For this reason, we deliver a lot of our products directly from our suppliers and manufacturers, to offer you a great price and a fresh braai and a warm fireplace.

PRIORITY DELIVERYWe will make sure you are kept in the loop at every single step of the way and we will have your order processed as a priority. Tracking number included.

FREE DELIVERYLook, it’s free but we are unable to provide an exact time or take specific delivery requests as we are at the mercy of our suppliers. We still do our best to deliver as quickly as possible and in most cases we are much quicker than the stated turn around time.

Mail us for any queries.
[email protected]

Your total R18,399.00

Delivery cost to be confirmed.

Get a Quote

See it in your space. Send a photo and measurements for a quote and a visual preview.

WhatsApp Us

UNDER THE GRIDS

Homefires 5 Burner Flat Top Gas Griller.
Cast iron below.

The Homefires 5 Burner Flat Top Gas Griller puts five cast iron burners under 430 stainless steel vaporiser plates and three round-bar stainless steel grids. Press the piezo ignition and you are away. The drip tray catches what falls, and when the last prawn comes off, the stainless steel dust cover goes back on. Lekker simple.

  1. Five cast iron burnersUnder 430 stainless steel vaporiser plates
  2. Three round-bar stainless steel gridsTwo large, one small
  3. Piezo ignition
  4. Stainless steel drip tray and dust cover
  5. Runs on LPG at 2.8 kPaRegulator with hose not included
  6. Installation manualUnder Plan your setup
Homefires 5 Burner Flat Top Gas Griller set into a stone outdoor counter, with a man cooking prawns and peppers and the sea beyond the garden

LUNCH WITH A VIEW

Prawns on, peppers on, nobody in a hurry.

Prawns down the middle, peppers alongside and five burners to keep it all moving. An outdoor kitchen is a fine place to spend an afternoon, and a griller this wide means the cook can stay in the conversation and stop cooking in shifts. Someone pass the lemon.

The stone counter, plants, tongs and food are not included. Ask us for the opening size before you build it in, and have a registered gas installer connect it.

BEFORE THE FIRST PRAWN

Plan the gas, then plan the menu.

THE GAS

A registered installer connects it.

Installation by a registered gas installer is required, and your installer supplies the gas pipes and fittings. The regulator with hose is not included. We do not install, so book an independent registered gas installer.

THE SPOT

Level, stable and well ventilated.

Use it on a level, stable, non-flammable surface and keep the ventilation openings clear. Do not use it in a fully enclosed patio without a chimney or a non-flammable exhaust hood and an efficient exhaust fan.

THE GRIDS

Three grids across five burners.

Two large round-bar grids of 340 × 397 mm and one small grid of 200 × 397 mm cover the five burners, with the vaporiser plates below them. Drips go to the stainless steel drip tray.

MEASURE THE WHOLE SETUP

Will it fit your space?

Open the full drawing
Homefires 5 Burner Flat Top Gas Griller dimension drawing, page 1 of 2: front, side and top views, in millimetres.
Page 1 of 2
Overall width × depth
900 × 500 mm
Total height
222 mm
Large grids (two), width × depth
340 × 397 mm
Small grid (one), width × depth
200 × 397 mm
Clearance to combustibles, each side
250 mm
Clearance to combustibles, rear
250 mm
Clearance above the cooking surface
1,500 mm
Burners
Five, cast iron
Gas
LPG
Material
Stainless steel

Leave room for the gas, the cover and the clearances.

These are approximate Home Fires sizes without the gas connection, not an opening size. Ask us for the height with the cover up and the opening size before you build it in. Keep combustibles 250 mm from the sides and rear and 1,500 mm above the cooking surface.

Planning notes

  • These are product sizes, not a building-opening size. Ask us for the opening size before you build it in.
  • Keep combustible materials outside the dashed lines. Use it on a level, stable, non-flammable surface.
  • The 900 width does not include the gas connection. These sizes are approximate.
  • Ask us for the height with the lid standing up before you plan the space above and behind it.
  • Your installer supplies the gas pipes and fittings. The regulator with hose is not included.

Download printable drawing (A4 PDF)

The drawing as text
  • ALL SIZES IN MILLIMETRES
  • Homefires 5 Burner Flat Top Gas Griller
  • Five-burner flat-top gas griller in stainless steel
  • 01 FRONT VIEW
  • 340 grid
  • 340 grid
  • 200 grid
  • Gas connection
  • 900 overall width
  • 02 SIDE VIEW
  • 222 total height
  • 500 overall depth
  • Front at the right.
  • 03 TOP VIEW
  • 900 overall width
  • Front at the bottom.
  • 04 COOKING GRIDS (THREE SECTIONS)
  • 500 overall depth
  • 340 width
  • 340 width
  • 200 width
  • 397 depth
  • 397 depth
  • Two large grids and one small grid are supplied.
  • 05 CLEARANCES FROM THE FRONT (SMALLER SCALE)
  • 1,500 above cooking surface
  • 250 side
  • 250 side
  • 06 CLEARANCES FROM THE SIDE (SMALLER SCALE)
  • 1,500 above cooking surface
  • 250 rear
  • Front at the right.
  • PLANNING NOTES
  • These are product sizes, not a building-opening size. Ask us for the opening size before you build it in.
  • Keep combustible materials outside the dashed lines. Use it on a level, stable, non-flammable surface.
  • The 900 width does not include the gas connection. These sizes are approximate.
  • Ask us for the height with the lid standing up before you plan the space above and behind it.
  • Your installer supplies the gas pipes and fittings. The regulator with hose is not included.

GOOD TO KNOW

Plan your setup.

Read the installation manual before you plan the gas connection.

Read the instruction manual

What is included?

The stainless steel griller with five cast iron burners, 430 stainless steel vaporiser plates, piezo ignition, two large and one small round-bar stainless steel grid, a stainless steel drip tray and a stainless steel dust cover. The regulator with hose is not included, and your installer supplies the gas pipes and fittings.

Which gas does it use?

LPG, at an operating pressure of 2.8 kPa. The listed gas consumption is 1,277 g/h and the listed heat output is 17.5 kW on LPG. The regulator with hose is not included, so ask us which one suits your setup.

Can I use natural gas?

The model we sell is the LPG one. The manual also has natural gas figures, but we do not list a natural gas version. If your home runs on natural gas, ask us before you order.

How much cooking space is there?

Three round-bar stainless steel grids: two large ones of 340 × 397 mm each and one small one of 200 × 397 mm.

Who must connect the gas?

Installation by a registered gas installer is required, and your installer supplies the gas pipes and fittings. We do not install, so arrange an independent registered gas installer for your setup.

Where can I use it?

On a level, stable, non-flammable surface, with the ventilation openings kept clear. Do not use it in a fully enclosed patio without a chimney or a non-flammable exhaust hood and an efficient exhaust fan.

Can I build it in?

Yes. It can stand on a countertop, or go into an existing brick-built opening. We do not have an exact cut-out or support size for this griller, and its body size is not a cut-out, so ask us for the opening size before you build it in. Keep the clearances: 250 mm to combustibles at the sides and rear, and 1,500 mm above the cooking surface.

How much space do I need?

The griller is about 900 mm wide, 500 mm deep and 222 mm high, without the gas connection. There is no published height with the dust cover standing up, so ask us before you plan the space above and behind it. Keep combustibles 250 mm from the sides and rear and 1,500 mm above the cooking surface. Your installer must follow the installation manual that comes with the unit.

What is it made of?

The griller, grids, dust cover and drip tray are stainless steel, the vaporiser plates are 430 stainless steel and the burners are cast iron.

Can I add a roasting dome or a rotisserie?

Yes. The roasting dome and the rotisserie kit are sold separately, and neither comes with this griller. Ask us about them before you order.

What does the warranty cover?

It has a 12-month Home Fires warranty from purchase for the original purchaser, with proof of purchase, qualified installation and maintenance. Corrosion, normal wear and commercial use are excluded. Ask us for the full terms.

Can you help with my setup?

Yes. Send us a photo of your space and its measurements and we will help you check the fit. We do not install: arrange the gas connection with an independent registered gas installer.
