Jetmaster FIRESCAPE 1060 Slow combustion Double Sided Built-in Fireplace

Built into your wall, with the fire on show from both sides.

From: Original price was: R56,414.40.Current price is: R53,399.00.

Save R3,015

SKU 40200014

In stock Delivery ETA: 5–7 working days

Complete your setup

See it in your space. Send a photo and measurements for a quote and a visual preview.

WhatsApp Us

A FIRE FOR BOTH SIDES

Everyone can see the fire in the Firescape 1060 Double-sided Built-in.

Build the Firescape 1060 Double-sided Built-in into the wall between two spaces, and the fire is on show from both sides through the glass. Vermiculite boards line the firebox, and the black mild-steel body and frame keep the look simple. Load it with wood or charcoal, close the door and settle in for a long winter evening.

  1. Glass on both sidesSee the fire from either side
  2. Vermiculite inner boardsLine the firebox
  3. Mild-steel body and frameBlack finish
  4. Burns wood or charcoalSlow combustion
  5. Poker and installation manualCome with the fireplace
Jetmaster Firescape 1060 double-sided fireplace in a white dividing wall, a log fire burning, a lounge in front and a family at the table seen through the glass

WHERE THE FAMILY GATHERS

Supper on one side, the couch on the other.

The table is laid, the family is talking and the fire glows between the dining room and the lounge. From the couch you get the flames and the laughter at once. On a cold winter evening, it is a place to gather on a cold winter evening, on both sides of the wall.

The wall, furniture, lights, plants and firewood are not included. The flue is built in by an independent installer.

A LITTLE PRACTICAL THINKING

Plan the heat and the flue early.

THE HEAT

Start with your room.

The listed heat output is 17 kW. The Output Calculator on this page uses that figure to compare the fireplace with your room. Use the result as a guide when you plan.

THE FIRE

Slow combustion, on show.

Vermiculite boards line the closed firebox, and the fire burns wood or charcoal behind glass. Close the door and keep the view of the flames on both sides.

THE FLUE

Plan the flue with the build.

The fireplace takes a 175 mm round flue (nominal size) from a collar in the centre of the top, and each separate flue section is 1,200 mm long. Plan the route and the roof exit with an independent installer before the building work starts.

MEASURE THE WHOLE SETUP

Will it fit your space?

Open dimension drawing
Firescape 1060 Double-sided Built-in dimension drawing: front, side and top views and flue, in millimetres.
Download the dimension drawing
Body width × height, without frame
1,044 × 590 mm
Body depth
539 mm
Outer box width
1,153 mm (with both frames)
Outer box height
658 mm (with both frames)
Outer box depth
592 mm (frame face to frame face)
Flue collar position
Centred on the top
Round flue diameter (nominal)
175 mm
Flue section length, each
1,200 mm
Material
Mild steel, black
Lining
Vermiculite inner boards
Fuel
Wood or charcoal
Heat output
17 kW

Plan the body, frame and flue together.

With both frames the outer box is 1,153 mm wide, 592 mm deep and 658 mm high, with the flue collar centred on top. The body alone is 1,044 × 590 × 539 mm. These are product sizes, not a building opening: your installer checks the unit, the cut-out and the clearances.

The drawing as text
  • ALL SIZES IN MILLIMETRES
  • Jetmaster FIRESCAPE 1060 Double Sided Built-in
  • Built-in wood or charcoal fireplace: slow combustion, with glass on both sides
  • 01 FRONT VIEW
  • Ø175 flue
  • 658 outer frame height
  • 1,153 outer frame width
  • 02 SIDE VIEW
  • 539 body depth
  • 592 with both frames
  • 590 body height
  • Glass door at the left and at the right.
  • The 539 is between the frames.
  • 03 TOP VIEW
  • 1,044 body width
  • 522 to centre
  • 522 to centre
  • 296 to centre
  • 296 to centre
  • The flue collar is centred on top:
  • 522 from the body sides, 296 from the outer frames.
  • 04 OPTIONAL FLUE (SMALLER SCALE)
  • Ø175
  • 1,200 flue section
  • One separate flue section, not
  • the installation height.
  • Ask us to confirm the Ø175
  • flue parts for your setup.
  • PLANNING NOTES
  • These are product sizes, not a building opening. Your installer checks the unit, the cut-out and the clearances.
  • Plan the opening, the flue and the safe clearances with your installer before the building work starts.
  • The body sizes are without the frames, the collar and the handles.
  • A poker and the installation manual come with the fireplace. The built-in model has no log box.
  • Not included: the flue pipe with collar, the cowl, the escutcheon plate, the insulation blanket, the building
  • materials and the installation.

GOOD TO KNOW

Plan your setup.

Plan the opening, the flue and the safe clearances with your installer before the building work starts.

What is included?

The Firescape 1060 double-sided fireplace with its mild-steel frame and vermiculite inner boards, plus a poker and the installation manual. Ask us to confirm the 175 mm flue-system parts for your setup.

How much heat does it give?

The listed heat output is 17 kW, and the Output Calculator on this page uses 17 kW to compare the fireplace with your room. The published heating range is up to 260 m². Treat that as a guide, not a promise: your room, ceilings and insulation decide the result.

Which fuel can I use?

Wood or charcoal. Close the door and the fire burns behind glass, with the flames on show on both sides.

Which flue does it need?

A 175 mm round flue (nominal size), from a collar in the centre of the top. Each separate flue section is 1,200 mm long. Have an independent installer plan the height, support, roof exit and any bends. We confirm the flue parts for your setup with your quote.

Are the flue pipe and cowl included?

No. Ask us to confirm the 175 mm flue-system parts for your setup. Send a photo and measurements for a product and flue configuration quote.

How much space do I need?

With both frames, the outer box is 1,153 mm wide, 592 mm deep and 658 mm high. The body alone is 1,044 mm wide, 590 mm high and 539 mm deep. These are product sizes, not a building opening or clearances. Have your installer confirm the cut-out and safe clearances against the actual unit.

Is this the built-in version?

Yes. This is the built-in Firescape 1060: it comes with a mild-steel frame and has no log box.

Does it come with an installation manual?

Yes. An installation manual is listed with the built-in fireplace. Read it with your installer before you plan the opening and the flue.

What does the guarantee cover?

The fireplace box has a 5-year Jetmaster guarantee from the invoice date against defects in materials and workmanship, with normal domestic use and maintenance. Flue pipes and cowls have 12 months; rust, discolouration and fair wear and tear are not covered. Parts that wear in use, such as the vermiculite boards, rope seals, door handles and glass, are not covered, and the installation must follow the manual. Ask us for the full terms.

Can you help with my setup?

Yes. Send a photo and measurements for a product and flue configuration quote. Arrange installation with an independent installer.
